BB4505C Antena de media onda negra de 32 pulgadas - NMO - 450-470 MHz UHF - Plano de tierra

  • Regular price $85.15 Sale price $74.27
    Precio unitario por

BB4505C


+ -
0 en existencia. Sujeto al tiempo de entrega de fábrica
Volume Price Breaks
Quantity: Unit Price:
100 $68.87
250 $65.06
500 $61.62
Tiempo de espera:  Ships in 6-8 Weeks

Los gastos de envío se calculan en la pantalla de pagos.

BB4505C Antena de media onda negra de 32 pulgadas - NMO - 450-470 MHz UHF - Plano de tierra

More InfoDocumentsSpecifications Reviews

La Laird B4505CN es una antena de látigo UHF negra de 33 pulgadas con una base NMO; se requiere un plano de tierra metálico.

*Esta antena requiere un soporte NMO. Haga clic aquí para encontrar todos los soportes NMO con orificio pasante o los soportes NMO magnéticos que tenemos.



More Information

The Laird BB4505C is a 33 inch black base loaded mobile UHF whip antenna with NMO base. This antenna requires a metal ground plane. This omnidirectional antenna ofers 5 dbi gain and 100 watts max power and operates in the 450MHz - 470MHz range.

Lairds’ongoing commitment to refinement in mechanical and electrical design has resulted in the most technically advanced mobile load coil antennas on the market. Exclusive features such as stainless steel whips, housings constructed with ABS material injected molded around a solid brass insert, and gold plated push pin contacts make Laird Technologies the obvious choice for quality and long lasting value for demanding mobile radio communications.

FEATURES

  • Long tuning ferrule allows for greater freedom in frequency adjustment without trimming
  • High performance mobile antenna operates on a No Ground plane (NGP) requirement
  • Straight Stainless steel corona ball stays on the rod – no metal interactions
  • Easy Installation / NMO mountable
  • 100% tested on a network analyzer

APPLICATIONS

  • Public Safety
  • Transportations/Logistics
  • Utilties
  • Military

Documents


Specifications

SKU BB4505C
Manufacturer Part Number BB4505C
Manufacturer Laird
Antenna Category UHF (380-600 MHz)
Working Frequency 450-470 MHz
Gain 5dB
Antenna Style Base Coil Antennas
Polarity Linear
Bands Single
SISO or MIMO SISO
Directional or Omni Omnidirectional
Max Input Power (W) 200
VSWR: < X: 1 2:01
Height/Length (inches) 33
Height/Length (mm) 838.2
Mount Style NMO Mount
Color Black
OK for Outdoor Use Yes
Vehicular Yes
Ground Plane Required Yes
Product Condition New
