GB8UM: Soporte magnético NMO con 12 pies. Cable RG-58/U y conector de engarce mini UHF
GB8UM-L
GB8UM: Soporte magnético NMO con 12 pies. Cable RG-58/U y conector de engarce mini UHF
More InfoDocumentsSpecifications ReviewsEste soporte magnético NMO de Laird-Antenex está optimizado para el montaje en techo de vehículos de una antena tipo NMO. Normalmente utilizado con antenas VHF o UHF, el GB8UM incluye una antena de 12 pies. Cable RG-58/U y engarzado Mini UHF
Si este no es el soporte NMO que está buscando, haga clic aquí para encontrar todos los soportes NMO que tenemos o envíe un correo electrónico a customerservice@arcadianinc.com para comunicarse con uno de los miembros de nuestro equipo de servicio al cliente.
More Information
High Quality NMO cable kits and NMO magnetic mounts were the flagship product of the original Antenex Corporation, founded in Glendale Heights, IL in 1990. The company?s passion and dedication to designing and manufacturing high-performance coaxial cables like GB8UM for Magnetic vehicular mounting of NMO antennas continues to drive the company's success today. Owned by Laird Technologies since 2006, this dedicated group of Land Mobile Radio (LMR) professionals use quality materials and workmanship to produce a superior product.
FEATURES
- Magnetic NMO Mount
- 12 Ft. RG-58/U Cable
- Mini UHF Crimp Connector Included
- Originally designed by Antenex
- 5 Year Factory Warranty
| Cable Type | Attenuation (dB/100 ft) | ||
| 150 MHZ | 450 MHZ | 900 MHZ | |
| RG-58/U | 5.40 | 10.20 | 16.10 |
| RG-58A/U | 6.20 | 12.50 | 20.00 |
| RG8X | 3.60 | 6.80 | 10.70 |
| Solid Teflon Cable | 4.80 | 9.00 | 13.50 |
Documents
Specifications
| SKU | GB8UM |
|---|---|
| Manufacturer Part Number | GB8UM-L |
| Manufacturer | Laird |
| NMO Mount Type | Magnetic NMO Mount |
| Mount Style | Magnetic NMO Mount |
| Connector 1 | Mini UHF Male/ Mini-PL259/ MPL |
| Cable Length (Mounts) | 12 Feet |
| Cable Type | RG-58/U |
| Cable Length (inches) | 144 |
| Cable Length (mm) | 43891.2 |
| Thickness/Diameter (inches) | 3.2 |
| Thickness/Diameter (mm) | 81.28 |
| Weight (lbs) | 1 |
| Weight (grams) | 454.55 |
| Color | Black |
| Connector Type | Connector - Rear |
| Vehicular | Yes |
| OK for Outdoor Use | Yes |
| Product Condition | New |
