MTRA61274CW2-001: Laird White MIMO Phantom Series 617-960/1350-2700 MHz SMA Male 2 Ft Coax Cable
MTRA61274CW2-001
Shipping calculated at checkout.
MTRA61274CW2-001: Laird White MIMO Phantom Series 617-960/1350-2700 MHz SMA Male 2 Ft Coax Cable
More InfoDocumentsSpecifications Reviews
The MTRA61274CB2 is a next generation product, offering 2-port MIMO functionality to Laird’s Phantom series product line. The product is designed to provide 3G/4G/ISM/UMTS and 802.11b/g/n operation at each port with an extended low band frequency coverage of 617-960/1350-2700 MHz. With optimized pattern coverage, the antenna provides an excellent solution for MIMO IoT/M2M applications.
***This item is subject to an MOQ of 5 pcs***
More Information
The MTRA61274CB2 is a next generation product, offering 2-port MIMO functionality to Laird’s Phantom series product line. The product is designed to provide 3G/4G/ISM/UMTS and 802.11b/g/n operation at each port with an extended low band frequency coverage of 617-960/1350-2700 MHz. With optimized pattern coverage, the antenna provides an excellent solution for MIMO IoT/M2M applications.
Each antenna port currently has 610 mm (24in) of LMR195 equivalent coax cables terminated with SMA Male connectors, but they can be configured to various cable lengths and connectors as the need arises.
Features and benefits:
- Covers 617-960 MHz and 1350-2700 MHz
- Operates simultaneously in more than eleven frequency bands supporting – LTE, cellular, Quadband GSM+UMTS / 3G, AWS, WI-FI, WLAN, WISP, and WIMAX
- Vertical polarization
- Omnidirectional gain patterns
- RoHS-compliant
Applications:
- LTE
- GSM 850/900
- GSM 1800/1900
- UMTS/WCMDA (3G)
- 802.11 b/g/n WLAN applications
- Bluetooth® devices
Documents
Specifications
| SKU | MTRA61274CW2001 |
|---|---|
| Manufacturer Part Number | MTRA61274CW2-001 |
| Manufacturer | Laird |
| Antenna Category | 4G/LTE (698-2700 MHz) |
| Working Frequency | 617-960 MHz |
| Gain | 2.5 dBi |
| Working Frequency 2 | 1350-2700 MHz |
| Gain 2 | 2.5 dBi |
| Antenna Style | Low Profile Antenna |
| Polarity | Vertical |
| Bands | Multi |
| SISO or MIMO | MIMO |
| Directional or Omni | Omnidirectional |
| Impedance | 50 ohm |
| Max Input Power (W) | 50 |
| VSWR: < X: 1 | < 2.5:1 |
| Horizontal/Azimuth Beamwidth | 360 |
| Height/Length (inches) | 5.12 |
| Height/Length (mm) | 130 |
| Width (inches) | 3.31 |
| Width (mm) | 84 |
| Thickness/Diameter (inches) | 3.74 |
| Thickness/Diameter (mm) | 95 |
| Weight (lbs) | 0.76 |
| Weight (grams) | 343 |
| Operating Temp (celsius) | -30°C to +70°C |
| Color | White |
| Cable Length (inches) | 24 |
| Cable Length (mm) | 600 |
| Connector 1 | SMA-Male |
| IP Rating | IP67 |
| OK for Outdoor Use | Yes |
| Vehicular | Yes |
| Product Condition | New |
