A7060-71304: FCC SlimLine Ultra Low Profile UHF Antenna with 1 Foot cable and SMA Female Connector

  • $313.50
    Unit price per

A7060-71304


+ -
9 Can ship immediately
Lead time for qty above 9:  Ships in 2-4 Weeks

Shipping calculated at checkout.

A7060-71304: FCC SlimLine Ultra Low Profile UHF Antenna with 1 Foot cable and SMA Female Connector

More InfoDocumentsSpecifications Reviews

A7060-71304: FCC SlimLine Ultra Low Profile UHF Antenna with 1 Foot cable and SMA Female Connector

Features:

  • Frequency Range: 864-869 Mhz / 902 - 928 Mhz
  • Polarization: Linear
  • Gain: 9 dBi
  • Connector: SMA Female


More Information


Documents


Specifications

SKU A706071304
Manufacturer Part Number A7060-71304
Manufacturer Times-7
Working Frequency 902-928 MHz
Antenna Category RFID (865-928 MHz)
Bands Multi
IP Rating IP65
Polarity Linear
Gain 9 dBi
Horizontal/Azimuth Beamwidth 80
Vertical/Elevation Beamwidth 45
Connector Type Connector - Side Flying Lead w/ SMA Female
Connector 1 SMA-Female
Cable Length (inches) 12
Cable Length (mm) 300
Height/Length (inches) 23.6
Height/Length (mm) 600
Operating Temp (celsius) -20 to 55
Thickness/Diameter (inches) 9.8
Thickness/Diameter (mm) 250
Width (inches) 0.3
Width (mm) 8
Weight (lbs) 2.6
Weight (grams) 1200
Material Fire Retardant Kydex
Product Condition New
